LITHOGRAPHY AND PHOTOABLATION SYSTEMS

Anvik Corporation is an emerging growth company engaged in the design, development, and manufacturing of advanced excimer-laser-based microlithography and photoablation systems for high-throughput production of microelectronic packages, flat-panel displays, printed circuit boards, flex electronics and displays, and MEMS.


HexScan: Anvik's High-Throughput Scanning Exposure Systems for
Microelectronic Packages | Displays | PCBs | Flex Products | MEMS


NexStepLow-Cost StepperHexScan 1010SDE

Results

RESEARCH AND TECHNICAL SOLUTIONS

Anvik's RTS Division carries out cost-effective research investigations in diverse product areas, offering customers the opportunity to explore and develop proprietary process technologies, materials, and manufacturing solutions for excimer laser lithography and direct photoablation applications.

See Some of Our Satisfied RTS Customers
